IBM DCS9550 1S1 User Manual
Page 36
Installation
IBM System Storage DCS9550 1S1 Storage Expansion Unit Installation, Service, and User Guide
21
2.6
Cabling the IBM System Storage DCS9550 1S1 Storage Expansion Unit
The following figures illustrates how to cable the DCS9550 1S1 Storage Expansion Unit to the
couplets (Unit 1 and Unit 2) and the couplets to each other.
Figure 2–5
DCS9550 1S1 Storage Expansion Unit: Unit #1 Cabling
Unit 1—A
Unit 1—B
Unit 1—C
Unit 1—E
Unit 1—F
Unit 1—G
Unit 1—H
Unit 1—P
Unit 1—S
Unit 1—D
