Specifications
AMPLIFIER SECTION
Continuous Average Power output (FTC)
All channels:
100 W per channel min. RMS at 8
, 2 channels driven from 20 H z
to 20 kHz with no more than
0.08% total harmonic distortion.
130 W per channel min.
RMS at 6 , 2 channels driven
from 1 kHz with no more than
0.1% total harmonic distortion.
Continuous Power output (DIN) 135 W at 6
Maximum Power output (EIAJ)
160 W at 6
Dynamic Power Output (Stereo) 2
× 250 W at 3
2
× 210 W at 4
2
× 130 W at 8
Total Harmonic Distortion:
0.08% at rated power
0.08% at 1 W output
IM Distortion:
0.08% at rated power
0.08% at 1 W output
Damping Factor:
60 at 8
Input Sensitivity and Impedance
PHONO:
2.5 mV, 50 k
LINE (CD, TAPE, DVD,
VIDEO 1-4):
200 mV, 50 k
MULTICHANNEL INPUT
(FRONT L/C/R, SURROUND
L/R, SURROUND BACK L/R):200 mV, 50 k
(SUBWOOFER):
36 mV, 50 k
COAXIAL 1, 2 (DIGITAL):
0.5 Vp-p, 75
DVD, VIDEO1-4:
1 Vp-p, 75
1 Vp-p, 75 (Y)
0.28 Vp-p, 75 (C)
COMPONENT VIDEO 1, 2:
1 Vp-p, 75 (Y)
0.7 Vp-p, 75 (P
B
, P
R
)
Output Level and Impedance
Rec out (TAPE, VIDEO 1, 2): 200 mV, 2.2 k
Pre out:
1 V, 470
ZONE2 OUT:
100 mV, 470
VIDEO (VIDEO 1, 2, MONITOR OUT):
1 Vp-p, 75
1 Vp-p, 75 (Y)
0.28 Vp-p, 75 (C)
COMPONENT VIDEO OUT: 1 Vp-p, 75 (Y)
0.7 Vp-p, 75 (P
B
, P
R
)
Phono Overload:
110 mV RMS at 1 kHz, 0.5% T.H.D.
Frequency Response:
20 Hz to 30 kHz: ±1 dB
(CD in Direct mode)
5 Hz to 100 kHz: +1 dB,-3 dB
(CD in Direct mode)
RIAA Deviation:
20 to 20 kHz : ±0.8 dB
Tone Control
Bass:
±10 dB at 100 Hz
Treble:
±10 dB at 10 kHz
Signal-to-Noise Ratio (Stereo)
Phono:
80 dB (IHF A, 5 mV input)
CD/Tape:
100 dB (IHF A, 0.5 V input)
Muting:
–50 dB
TUNER SECTION
FM
Tuning Range:
87.5 to 108.0 MHz (50-kHz steps)
Usable Sensitivity
Mono:
11.2 dBf, 1.0 µV (75 IHF)
0.9 µV (75 DIN)
Stereo:
17.2 dBf, 2.0 µV (75 IHF)
23 µV (75 DIN)
50 dB Quieting Sensitivity
Mono:
17.2 dBf, 2.0 µV (75 )
Stereo:
37.2 dBf, 20 µV (75 )
Capture Ratio:
2.0 dB
Image Rejection Ratio:
40 dB
IF Rejection Ratio:
90 dB
Signal-to-Noise Ratio
Mono:
76 dB
Stereo:
70 dB
Alternate Channel Attenuation:
55 dB
Selectivity:
50 dB (DIN)
AM Suppression Ratio:
50 dB
Total Harmonic Distortion
Mono:
0.2%
Stereo:
0.3%
Frequency Response:
30 Hz to 15 kHz, ±1.0 dB
Stereo Separation:
45 dB at 1 kHz
30 dB at 100 Hz to 10 kHz
AM
Tuning Range:
530 to 1,710 kHz (10 kHz steps)
Usable Sensitivity:
30 µV
Image Rejection Ratio:
40 dB
IF Rejection Ratio:
40 dB
Signal-to-Noise Ratio:
40 dB
Total Harmonic Distortion:
0.7%
GENERAL
Power Supply:
AC 120 V, 60 Hz
Power Consumption:
5.5 A
Dimensions (W
× H × D):
17-1/8"
Ч 6-7/8" Ч 18-1/8"
Weight:
36.4 lbs.
REMOTE CONTROLLER
Transmitter:
Infrared
Signal range:
Approx. 16 ft.
Power supply:
Two “AA” batteries (1.5 V
× 2)
Specifications and features are subject to change without notice.
