SECTION 12—SCOOTER ACCESSORIES

Installing/Removing/Using the Walker Holder

ƽ INSTALLATION WARNINGS

After ANY adjustments, repair or service and BEFORE use, make sure that all

attaching hardware is tightened securely.
The installation of the walker holder onto the back of the scooter seat significantly

increases the length of the scooter. When turning the scooter or swiveling the

scooter seat, it is important to take note of this increased length - otherwise, injury

and/or damage to the surrounding property may result.

Installing/Removing the Walker Holder

NOTE: Reverse this procedure to remove the walker holder.
NOTE: For this procedure, refer to FIGURE 12.3.
1. If necessary, loosen but DO NOT

remove the mounting knob.

2. Install the walker holder into the

accessory tube.

3. Thread the mounting knob into the

welded nut on the accessory tube.

Securely tighten.

Using the Walker Holder

NOTE: For this procedure, refer to FIGURE 12.4.
1. Fold walker. Refer to walker

instructions.

NOTE: Walker MUST be folded before using

walker holder.
2. Hang folded walker on walker holder

hooks.

3. Secure walker with hook and loop

straps.

Seat

Accessory

Tube

Walker Holder

Seat

Mounting

Knob

Hook

Hook and

Loop Strap
