Invacare Formula - Manual (Page 99)

Back Recline Shear Link Assemblies
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1125758 Kit, Recline Shear Link Assembly Conventional
(Pair) 1 1 1 A
Screw, Hex Head w/ Patch (1/4-20 x 5/8") 1 4 2
Washer (1/4 x 1/2 x 1/16") 1 4 3
Plate, Shear Adapter 1 2 4
T-Nut (1/4-20) 1 4 5
Locknut, Low Profile (3/8-16) 1 4 6
Washer, Flat (3/8 x 11/16 x 1/16") 1 4 7
Link, Recline Shear, Black - Right 1 1 8
Link, Recline Shear, Black - Left 1 1 8
Stand-Off, Recline Shear Link 1 4 9
1168997 Kit, Recline Shear Link Assembly, Contoura/Curve
Contoura (Pair) 1 1 10 B
Screw, Hex Head w/ Patch (1/4-20 x 5/8") 1 4 11
Washer (1/4 x 1/2 x 1/16") 1 4 12
T-Nut (1/4-20) 1 4 13
Locknut, Low Profile (3/8-16) 1 4 14
Washer, Flat (3/8 x 11/16 x 1/16") 1 4 15
Link, Recline Shear, Black - Right 1 1 16
Link, Recline Shear, Black - Left 1 1 16
Stand-Off, Recline Shear Link 1 4 17
1131413 Adapter, Recline Shear Contoura (16" W) 1 2 18 C
1122580 Adapter, Recline Shear Contoura (18" W) 1 2 18 C
1122623 Adapter, Recline Shear Contoura (20" W) 1 2 18 C
1131414 Adapter, Recline Shear Contoura (22" W) 1 2 18 C
1131415 Adapter, Recline Shear Contoura (24" W) 1 2 18 C
1161800 Adapter, Recline Shear, Curve Contoura (16" W) 1 2 18 D
1161653 Adapter, Recline Shear, Curve Contoura (18" W) 1 2 18 D
1161658 Adapter, Recline Shear, Curve Contoura (20" W) 1 2 18 D
1161959 Adapter, Recline Shear, Curve Contoura (22" W) 1 2 18 D
1161823 Adapter, Recline Shear, Curve Contoura (24" W) 1 2 18 D
A - Includes items 2-9. The Recline Shear Link and Recline Shear Link Stand-Off were revised as of 6/28/10. The Shear Link
is now made of thicker material and the Stand-Off is thinner. The kit is backward compatible to all chairs in the field.
B - Includes items 11-17. The Recline Shear Link and Recline Shear Link Stand-Off were revised as of 6/28/10. The Shear
Link is now made of thicker material and the Stand-Off is thinner. The kit is backward compatible to all chairs in the field.
C - Not used for Curve Contoura. For use on Contoura only.
D - Not used for Contoura. For use on Curve Contoura only.
