Invacare Formula - Manual (Page 131)

Recline and Tilt/Recline Arms without Mounting Hardware
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1082910 Pad, Arm w/ Elbow Stop, Desk Length, Urethane,
Black - Right (13" L x 3" W) 1 1 1
1082911 Pad, Arm w/ Elbow Stop, Desk Length, Urethane,
Black - Left (13" L x 3" W) 1 1 1
1090190 Kit, Arm Pad w/ Screws and Elbow Stop, Desk
Length, Urethane, Black (13" L x 3" W) (Pair) 2 1 1
1082912 Pad, Arm w/ Elbow Stop, Full Length, Urethane,
Black - Right (17" L x 3" W) 1 1 1
1082913 Pad, Arm w/ Elbow Stop, Full Length, Urethane,
Black - Left (17" L x 3" W) 1 1 1
1090191 Kit, Arm Pad w/ Screws and Elbow Stop, Full
Length, Urethane, Black (17" L x 3" W) (Pair) 2 1 1
1086992 Arm Assembly w/o Arm Pad, Desk Length, Black -
Right 1 1 2 A,F
1086993 Arm Assembly w/o Arm Pad, Desk Length, Black -
Left 1 1 2 A,F
1087012 Arm Assembly w/o Arm Pad, Full Length, Black -
Right 1 1 2 B,F
1087013 Arm Assembly w/o Arm Pad, Full Length, Black -
Left 1 1 2 B,F
1008432 Screw, Socket Button Head (1/4-20 x 1-1/4") 1 3 3
1026103 Washer, Nylon (1/4 x 1/2 x 1/32") 1 2 4
0028202 Tube, Extension, Full Length 1 1 5
1027095 Plug Button, Black (7/8") 1 1 6
1107155 Screw, Phillips Pan Head Tap (#10-32 x 1-1/4") 1 2 7
1028755 Screw, Phillips Pan Head (#10-32 x 5/8") 1 1 8 C
1107155 Screw, Phillips Pan Head Tap (#10-32 x 1-1/4") 1 1 8 D
1079203 Decal, Warning Pinch Point 1 1 9
1115392 Tube, Arm, Support, Black 1 1 10
1115393 Tube, Slide, Adjustable, Black 1 1 11
1082842 Plug, Arm, Black 1 1 12
7930333 Locknut (1/4-20) 25 3 13
1082927 Tube, Arm, Black 1 1 14
1091870 Screw, Socket Button Head w/ Patch (1/4-20 x 3/4") 1 1 15
1095437 Arm Pivot Assembly 1 1 16 G
1165484 Washer, Nylon (1/4 x 1/2 x 1/32") 1 2 17
1119268 Kit, Slide Tube w/ Arm Support (Pair) 2 1 E
A - Includes Items 3,4,6, and 9-17.
B - Includes Items 3-6 and 8-17.
C - Used for full length arms only
D - Used for desk length arms only
E - Not Shown. Assembly includes 2 ea. of item numbers 9, 10 and 11
F - When placing an order for item 2, you must specify as a note "For Tarsys 2GTR seating" or "For Formula TRE seating".
G - The Arm Pivot Assembly Pin faces down for Tarsys 2GTR and faces up for the Formula TRE powered seating NOTE:
130
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-041
