Invacare Formula User Manual
Page 78
Contoura Back without Mounting Hardware - Before
5/15/09
NOTE: When changing seat width on any system that has Recline and Contoura Seating (Tilt/Recline,
Tilt/Recline/Elevate or Recline Only) you must First look up special quote # C-100628042246 for directions
on how to order the Back and all additional components that may be required for changing seat width
through the Equipment Configurator.
NOTE: Extruded back canes come in one back height only. Back cane material height for the contoura
extruded back canes measure approximately 20-1/2". Overall back height from the seat pan to top of the
extruded back cane is approximately 23". Only the Back Assembly needs to be replaced when changing
back heights. Contoura Backs for ADJASBA Seating do not use the 24" wide selection
#1 Back Assembly without Hardware 16", 18", 20", 22", 24" Wide
Overall
Back
Height
24" Wide
Material
Back
Height
16" Wide
18" Wide
20" Wide
22" Wide
1132832
1132831
1132830
1132829
1132828
20"
25"
1132827
1132826
1124734
1124733
1132825
24"
29"
NOTE: When changing seat width on any system that has Recline and Contoura Seating (Tilt/Recline, Tilt/Recline/Elevate or Recline Only)
you must First look up special quote # C-100628042246 for directions on how to order the Back and all additional components that may be
required for changing seat width through the Equipment Configurator.
#2 Back Pan with Vinyl Edge Trim 16", 18", 20", 22", 24" Wide
Overall
Back
Height
24" Wide
Material
Back
Height
16" Wide
18" Wide
20" Wide
22" Wide
1131409
1131408-NLA
1131407
1131406
1131405
20"
25"
See Note(s) A
1131412
1131411
1122453
1122454
1131410
24"
29"
A - Item is No Longer Available. Back Assembly, part # 1132831 must be purchased for replacement.
NOTE:
#3 Back Cushion Assembly 16", 18", 20", 22", 24" Wide
Overall
Back
Height
24" Wide
Material
Back
Height
16" Wide
18" Wide
20" Wide
22" Wide
1132824-NLA
1132823
1132822
1132821
1132820
20"
25"
See Note(s) B
1132819-NLA
1132818
1125642
1125641
1132817
24"
29"
See Note(s) A
A - Item is No Longer Available. Back Assembly, part # 1132827 must be purchased for replacement.
B - Item is No Longer Available. Back Assembly, part # 1132832 must be purchased for replacement.
NOTE:
77
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-041
