Personal Back10 (TALL Regular/TALL Plus) Mounting
Hardware
Conventional Recline w/ BPO Option
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1132748 Kit, Personal Back10 Tall Back Mounting Hardware
For Conventional Recline 16-20" Wide 2 1 1 A
Washer (1/4 x 1/2 x 1/16") 1 4 2
Screw, Hex Head w/ Patch (1/4-20 x 1/2") 1 4 3
Bracket, Personal Back10 Tall, For Conventional
Recline, Black (16 - 20" W) 1 2 4
T-Nut (1/4-20) 1 4 5
1133122 Kit, Personal Back10 Tall Back Mounting Hardware
For Conventional Recline 20-24" Wide 2 1 1 A
Washer (1/4 x 1/2 x 1/16") 1 4 2
Screw, Hex Head w/ Patch (1/4-20 x 1/2") 1 4 3
Bracket, Personal Back10 Tall, For Conventional
Recline, Black (20 - 24" W) 1 2 4
T-Nut (1/4-20) 1 4 5
A - Includes items 2-5 and is used for a Personal Back10 Tall (Regular or Plus) model only NOTE:
198
