Headrest Support Assembly, Tarsys
Item
Number Part Number Description Note
Quantity Per
Package Assembly
0127700 Headrest, Curved (6" W x 7" H) 1 1 1
0128000 Headrest, Two-Step (8-1/2" W x 5-1/2" H) 1 1 1
0022600 Kit, Headrest w/ Screws, Adjustable, Small, Otto
Bock
(9" W x 3-1/2" H) 1 1 1
0022400 Kit, Headrest w/ Screws, Adjustable, Large, Otto
Bock (12" W x 6" H) 1 1 1
0197024 Fixture Assembly, Offset Support 1 1 2 A
0271524 Tube, Offset Fixture, Black 1 1 3
1077076 Plug Button, Square (1/2") 1 2 4
0271124 Collar, Offset Fixture Tube 1 1 5
0288606 Screw, Set Socket Cup Point (#10-24 x 3/16") 1 1 6
0271224 Half Clamp, Non-Threaded Holes 1 1 7
0271324 Half Clamp, Threaded Holes 1 1 8
1027268 Screw, Allen Head (1/4-20 x 1") 1 3 9
0271424 Tube, Fixture Adjustment 1 1 10
0283724 Ring, Fixture Clamp 1 1 11
0067006-NLA NLA - Screw, Cap, Socket Head (#10-32 x 1/2") 1 3 12
1124686 Kit, Conventional Headrest Mounting 1 1 13 B
1124685 Kit, Contoura Headrest Mounting 1 1 14 B,C
0273100 Kit, Headrest Clamp, Lever Style 1 1 15 D,F
0237422-NLA NLA - Clamp, Small Bottom Half 1 1 16 E
0237522-NLA NLA - Clamp, Small Top Half 1 1 17 E
1072439 Knob, Adjustment, Black (3/4" L Threads) 1 1 18
0288706 Screw, Socket, Flat Head (1/4-20 x 1") 1 2 19
1025736 Locknut (1/4-20) 1 2 20
A - Includes items 3-12
B - Individual components are not available
C - The contoura headrest mounting hardware is used for double spreader bar applications as well.
D - Includes items 16-20. Item 18 Adjustment Knob was replaced with an Adjustment Lever. The Lever is not available as a
separate part. The knob Part # 1072439 is still sold separately and is interchangeable with the Lever.
E - Clamp is no longer available individually. See item 15 Clamp Assembly part number 0273100.
F - Hardware can also be used with an Invacare Personal Back.
NOTE:
