Recline Actuator Motor and Mounting Hardware
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1125635 Motor, Recline Actuator - MK5 1 1 1 D
1146350 Motor, Recline Actuator - MK6i 1 1 1 C
1125752 Kit, Recline Actuator Motor Mounting Hardware
Conventional 1 1 2 A
Screw, Shoulder Hex Socket Head (3/8 x 2-3/4",
5/16-18) 1 1 3
Washer, Flat (5/16 x 5/8 x 1/16") 1 1 4
Locknut (5/16-18) 1 2 5
Spacer (3/8 x 1 x 1/2") 1 2 6
Bushing, Actuator Motor (3/8 x 3/4 x 5/32") 1 2 7
Screw, Shoulder Hex Socket Head (3/8 x 1-3/4",
5/16-18) 1 1 8
1125753 Kit, Recline Actuator Motor Mounting Hardware
Contoura 1 1 9 B
Screw, Shoulder Hex Socket (3/8 x 2", 5/16-18) 1 1 10
Washer, Flat (5/16 x 5/8 x 1/16") 1 1 11
Locknut (5/16-18) 1 2 12
Bushing, Actuator Motor (3/8 x 3/4 x 5/32") 1 2 13
Screw, Shoulder Hex Socket Head (3/8 x 1-3/4",
5/16-18) 1 1 14
A - Includes items 3-8
B - Includes items 10-14
C - Used with MK6i Electronics only. Includes the Actuator Motor and Bushings. NOTE: Part # 1136915 referenced on the
motor is not available, refer to part # 1146350.
D - Includes the Actuator Motor and Bushings. NOTE: Part # 1122257 referenced on the motor is not available, refer to part #
1125635.
NOTE:
