Shroud Covers Before 3/1/07
Conventional Tilt, Tilt w/ BPO or Tilt-Elevate w/ MK6i Electronics
NOTE: MK6i connectors are bundled and cable-tied to the MK6i Connector Shroud Mounting Tray
Assembly item #11
Item
Number Part Number Description Note
Quantity Per
Package Assembly
Shroud, Cover 1 1 14
Shroud, Back 1 1 15
Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 4 16
1140269 Kit, TRECM/TAC/MK6i Connector Shrouds and Mtg.
Hdwr. 20-24" Wide For Conventional Tilt Only 1 1 12 D
Screw, Phillips Pan Head w/ Patch (#10-32 x 3/8") 1 2
Bracket, Spreader Bar, Black - Right 1 1 2
Bracket, Spreader Bar, Black - Left 1 1 2
Screw, Hex Head (1/4-20 x 1-1/2") 1 4 3
Spacer, Coved (1/4 x 11/16 x 1/2") 1 8 4
Locknut (1/4-20) 1 2 5
Tube, Spreader Bar, Black (20 - 24" W) 1 1 6
Collar, Anti-Rattle (7/8") 1 2 7
Screw, Hex Head (1/4-20 x 5/8") 1 2 8
Locknut (1/4-20) 1 4 9
Plate, Mounting 1 1 10
TRECM/SAC/TAC/MK6i Connector Shroud
Mounting Tray Assembly 1 1 11
Screw, Thumb (#10-32 x 1/2") 1 1 13
Shroud, Cover 1 1 14
Shroud, Back 1 1 15
Screw, Phillips Pan Head Tap (#10-32 x 1/2") 1 4 16
1095502 Package, Tie Wrap (11-1/2" L) 10 1 E
A - Includes items 2-4 and 6-11
B - Includes items 2-12
C - Includes (part #1079316 Screw - Not Shown and not used for MK6i application) and items 2-4, 6-11 and 13-16
D - Includes (part #1079316 Screw - Not Shown and not used for MK6i application) and items 2-11 and 13-16
E - Not Shown NOTE:
146
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 04-041
