PCM-9575 User’s Manual 28
3.2.2 Connections to Toshiba LTM15C151A
(1024 x 768 TFT color LCD)
28 B5 16 P7
29 GND 3 GND
30 VDD 1 +5 V
31 VDD 2 +5 V
Table 3.2: Connections to Toshiba LTM15C151A
LTM15C151A PCM-9575 CN11
Pin Name Pin Name
CN1-1 GND CN 11-33 GND
CN1-2 NCLK CN 11-35 LDSCLK1
CN1-3 NC
CN1-4 NC
CN1-5 GND CN 11-3 GND
CN1-6 OR0 CN 11-9 PD0
CN1-7 OR1 CN 11-11 PD2
CN1-8 OR2 CN 11-13 PD4
CN1-9 OR3 CN 11-15 PD6
CN1-10 OR4 CN 11-17 PD8
CN1-11 OR5 CN 11-19 PD10
CN1-12 GND CN 11-3 GND
CN1-13 OG0 CN 11-21 PD12
CN1-14 OG1 CN 11-23 PD14
CN1-15 OG2 CN 11-25 PD16
CN1-16 OG3 CN 11-27 PD18
CN1-17 OG4 CN 11-29 PD20
CN1-18 OG5 CN 11-31 PD22
CN1-19 GND CN 10-1 GND
CN1-20 OB0 CN 10-3 PD24
CN1-21 OB1 CN 10-5 PD26
CN1-22 OB2 CN 10-7 PD28
CN1-23 OB3 CN 10-9 PD30
CN1-24 OB4 CN 10-11 PD32
Table 3.1: Connections to Toshiba LTM10C209A
