C.20 LCD Signal Mapping
Table C.20: LCD Signal Mapping
Pin
Name
16-bit
DSTN
24-bit
DSTN
18-bit
TFT
24-bit
TFT
36-bit
TFT
PD0 LB3 B0 R00
PD1 LB2 B1 R10
PD2 LB1 LB1 B0 B2 R01
PD3 LB0 LB0 B1 B3 R11
PD4 UB3 B2 B4 R02
PD5 UB2 B3 B5 R12
PD6 UB1 UB1 B4 B6 R03
PD7 UB0 UB0 B5 B7 R13
PD8 LG3 G0 R04
PD9 LG2 LG2 G1 R14
PD10 LG1 LG1 G0 G2 R05
PD11 LG0 LG0 G1 G3 R15
PD12 UG3 G2 G4 G00
PD13 UG2 UG2 G3 G5 G10
PD14 UG1 UG1 G4 G6 G01
PD15 UG0 UG0 G5 G7 G11
PD16 LR3 R0 G02
PD17 LR2 LR2 R1 G12
PD18 LR1 LR1 R0 R2 G03
PD19 LR0 LR0 R1 R3 G13
PD20 UR3 R2 R4 G04
PD21 UR2 UR2 R3 R5 G14
PD22 UR1 UR1 R4 R6 G05
PD23 UR0 UR0 R5 R7 G15
PD24 B00
PD25 B10
PD26 B01
PD27 B11
PD28 B02
PD29 B12
PD30 B03
PD31 B13
PD32 B04
PD33 B14
PD34 B05
PD35 B15
