PCM-9575 User’s Manual 146
E.1 PCM-10586-5A00 cable kit for PCM-9575
The PCM-9575 requires several cables for normal operation. You can
make them yourself or purchase an optional cable kit assembly, which
includes the following:
PCM-10586-5V00 cable kit for PCM-9575
Part No.
Cable
Description
PCM-
9575
Connector
Terminating Connector
1701440350
2.5" and 1.8"
IDE
CN14
44-pin, 2 mm, female
IDC (350 mm)
1701440452
3.5" IDE
DMA/66 (40
pin)
CN16
40-pin, 2.54 mm, female
IDC(450 mm)
1701340603
Dual Floppy,
3.5" and 5.25"
(34p)
CN18 34-pin Dual Floppy
1701260250 Parallel Port CN25 25-pin female DSUB
1701100202
Network, 10-
Base-T
CN12 RJ45 8-pin modular jack
1701160101 VGA CRT CN1
2 x 8 pin header (2 mm)
15-pin DSUB
1700000190
Keyboard and
PS/2 mouse
CN25
5-pin circular DIN, 6-pin
circular DIN
1703030300
Peripheral
power (-5V and
-12V)
CN27 (3-conductor)
1701400181
COM 1 - 4
cable
CN19
40-pin, 9-pin male DSUB
x4
1700160160 Audio Cable CN4
F3.5mm 16-pin, five
female phone jacks
