27 Chapter 3 Software Configuration
3.2 Connections to Three Standard LCDs
The following tables illustrate typical LCD connection pinouts for the
PCM-9575.
3.2.1 Connections to Toshiba LTM10C209A
(640 x 480 TFT color LCD)
Table 3.1: Connections to Toshiba LTM10C209A
LTM10C209A PCM-9575 CN11
Pin Name Pin Name
1 GND 3 GND
2 CLK 35 SHFCLK
3 GND 34 GND
4 R0 27 P18
5 R1 28 P19
6 R2 29 P20
7 GND 33 GND
8 R3 30 P21
9 R4 31 P22
10 R5 32 P23
11 GND 34 GND
12 G0 19 P10
13 G1 20 P11
14 G2 21 P12
15 GND 8 GND
16 G3 22 P13
17 G4 23 P14
18 G5 24 P15
19 GND 8 GND
20 ENAB 37 M/DE
21 GND 4 GND
22 B0 11 P2
23 B1 12 P3
24 B2 13 P4
25 GND 4 GND
26 B3 14 P5
27 B4 15 P6
