3 Chapter 1 General Information
1.2 Features
• Embedded VIA low-power Eden/Ezra processor
• EBX form factor which supports both PC/104-Plus and PCI slot
• Supports one 36 bit TFT LCD panel, with up to 1024 x 768 resolu-
tion
• Supports 2 channel LVDS interface
• 100/10Base-T Ethernet interface, IEEE 802.3U compatible
• Supports wake-on-Lan with ATX power supply
• TV-out function supports NTSC and PAL formats
• 4 serial ports (three RS-232 and one RS-232/422/485)
• USB interface complies with USB Rev. 1.10
• 62-level Watchdog timer by system reset or IRQ
• 2 IDE channels for HDD and CD-ROM
1.3 Specifications
1.3.1 Standard EBX SBC Functions
• CPU: OnboardVIA Ezra 800MHz (PCM-9575F-Q0A1) or
VIA Eden 400 MHz (PCM-9575F-J0A1) or
VIA Eden 667Mhz processor (PCM-9575F-M0A1)
• BIOS: Award 256 KB Flash memory
• System memory: One DIMM socket accepts 64 MB up to 512 MB
SDRAM
• System Chipset: VIA PL133 chipset , VT8606T (TwisterT ) &
VT82C686B
• Cache memory: 128KB L1 and 64 KB L2 cache memory on the pro-
cessor
