PCM-9575 User’s Manual

8

Chapter 2 Installation

2.1 Jumpers

The PCM-9575 has a number of jumpers that allow you to configure your
system to suit your application. The table below lists the functions of the
various jumpers.

2.2 Connectors

On-board connectors link the PCM-9575 to external devices such as hard
disk drives, a keyboard, or floppy drives. The table below lists the func-
tion of each of the board’s connectors.

Table 2.1: Jumpers

Label

Function

JP1

PCI VIO select

JP2

LAN controller power select (Rev A101only)

JP3

DOC2000 address select

JP4

CMOS clear

JP5

Watchdog timer action

JP6

COM2 RS232/422/485 setting

S1

Panel type select

Table 2.2: Connectors

Label

Function

CN1

TV-out connector

CN2

Audio CD in connector

CN3

ATX feature connector

CN4

Audio connector

CN5

EBX Main Power connector

CN6

Backlight control connector
