30
Transparent with Untagged Management
Transparent with Untagged Management mode passes tagged traffic between the
DATA port and the OPTICS (or UPLINK) port and allows untagged traffic to be
considered management domain traffic (untagged).
To configure this mode, do the following:
1. Set the management DIP switch ON for the ports using management (in this
example it is the OPTICS (or UPLINK) port: 3 = ON). To enable External
Management (EXT MGMT), set DIP Switch 1 to ON. (otherwise, leave DIP Switch
1 in the OFF position (default from factory) to disable EXT MGMT)
2. Set Transparent Mode to allow both tagged data and untagged management
traffic to pass:
a. In the Main Configuration screen, press the space bar and type config. The
Configuration Screen displays:
Transparent Mode – with either (not both) Data and Optics Mgmt dipswitches
set to on, all traffic passes between Optics and Data port EXCEPT what has
been defined as the Management Domain. The Management Domain can either be
efined as untagged traffic or traffic with a specified VLAN ID. d
In Transparent Mode with BOTH Optics and Data Mgmt dipswitches set to off,
ll traffic passes between the Optics and Data Ports. a
efault Mode – the unit passes only Untagged Packets. D
he unit is currently in Default Mode . T
Enter Y for Transparent Mode, N for no Transparent Mode or to
move to other options [ Y ]
b. Enter Y in the Transparent Mode field and press any key (except S or Q) to
open the Transparent Mode Setup screen.
TRANSPARENT MODE SETUP
Is a VLAN tag required on Management packets? [ N ]
er Y for Extra Tagging. Do you want to enter the Extra Tag mode? Ent
nter N if you do not want Extra Tags [ N ] E
re VLAN Tags required on the EXT Port? [ N ] A
Type S or F3 to save the new information
ype Q of F4 to quit and cancel changes T
Reboot is required for any change to take affect.
c. Press S or F3 to save without setting any transparent mode options. This will
set all untagged traffic as management (
Is a VLAN tag required on
Management packets? [ N ]
)
.
d. Type reboot. In this mode tagged and untagged data can pass from the
OPTICS and DATA ports. If the EXT MGMT DIP switches are enabled,
untagged packets are allowed access to management.
