SX-200 General Information Guide
224 Revision A 50003510
The table below describes receiver combinations that are available in a SPINE Bay.
Physical Characteristics
SX-200 SPINE Maximum Receiver Combinations Available
CLASS Receivers DTMF Receivers
0 7
1 6
2 5
3 4
4 3
5 1
Physical Characteristics
SX-200 EL/ML Universal Cabinet
Cabinet Height 28 cm 11 inches
Cabinet Width 43 cm 17 inches
Cabinet Depth 43 cm 17 inches
Cabinet Weight (cards installed) 21 kg 47 pounds
SX-200 ML (FD) Cabinet and SX-200 LIGHT Peripheral Cabinet
Cabinet Height 48.0 cm 19.0 inches
Cabinet Width 22.9 cm 9.0 inches
Cabinet Depth 42.0 cm 16.5 inches
Cabinet Weight (cards installed) 19 kg 42 pounds
SX-200 SPINE Peripheral Bay
Height 18.0 cm 7.0 inches
Width (12 modules plus Control Module) 55.0 cm 21.5 inches
Depth 27.0 cm 10.5 inches
SX-200 IP Node
Height 7 cm 2.75 inches
Width 48.3 cm 19.0 inches
Depth 39.4 cm 15.5 inches
Weight 7.35 kg 16.19 lb
