A-4
MS-6570 ATX Mainboard
Using 4- or 6-Channel Audio Function
After installing the audio driver, you are able to use the 4-/6-channel
audio feature now. To enable 4- or 6-channel audio operation, first connect 4
or 6 speakers to the appropriate audio connectors, and then select 4- or 6-
channel audio setting in the software utility.
There are two ways to utilize the function and connect the speakers to
your computer:
„ Using the optional S-Bracket
If your motherboard supports S-Bracket and you have installed S-
Bracket in the computer, you can connect two speakers to back
panel’s Line-Out connector, and the rest of speakers to S-Bracket.
„ Using the back panel only
If you do not have a S-Bracket, you can connect all speakers to the
audio connectors on the back panel.
