3-18
MS-6570 ATX Mainboard
MC97 Modem
Auto allows the mainboard to detect whether a modem is used. If a modem
is detected, the onboard MC’97 modem controller will be enabled; if
not, it is disabled. Disable the controller if you want to use other control-
ler cards to connect a modem. Settings: Auto, Disabled.
OnChip USB
This setting allows you to enable/disable the onboard USB controller.
Selecting [V1.1+V2.0] enables the system to support both USB 1.1 and
2.0 spec. Setting options: Disabled, V1.1, V1.1+V2.0.
USB Keyboard Support
Select Enabled if you need to use a USB-interfaced keyboard in the
operating system. Setting options: Enabled, Disabled.
OnChip 1394
This item allows you to enable/disable the onboard IEEE1394 controller.
Setting options: Auto and Disabled.
OnChip Lan (nVIDIA)
Setting to [Auto] allows the BIOS to auto-detect the nVIDIA LAN
controller and enable it. Setting options: Auto and Disabled.
MAC Address (nVIDIA)
Setting to [Enabled] allows users to manually update the MAC address
under MAC (NV) Address Input. Setting options: Enabled and Disabled.
MAC Address Input (nVIDIA)
Users can key in the MAC (NV) address in this field.
Onboard Super IO Device
Press
