1
Errata H
Comtech EF Data Documentation Update
Subject: Revised Options Table
Date: October 26, 2006
Document: CDM-570/570L Satellite Modem with Optional IP Module,
Installation and Operation Manual, Rev. 4, dated April 12, 2006
Part Number: MN/CDM-570L.EH4
Collating Instructions: Attach this page to page 6-63
Comments:
Added Options 18 and 19 to the options table to read:
Change Specifics:
Option
Number
Option
Type
Displayed
Code
Description
01 Hardware 150W BPSU 150 Watt, 48 volt BUC PSU
02 Hardware 100W BPSU 100 Watt, 24 volt BUC PSU
03 Hardware RS Codec Reed-Solomon Codec
04 Hardware TPC Codec Turbo Product Codec
05 Hardware TPC/LDPC TPC/LDPC Codec
06 Hardware IP Module IP Traffic Module
07 Hardware H/W Exp-1 Future Hardware Expansion 1
08 Hardware H/W Exp-2 Future Hardware Expansion 2
09 FAST 2048 kbps 2048 kbps max data rate
10 FAST 5000 kbps 5000 kbps max data rate
11 FAST 8PSK/8QAM 8-PSK and 8-QAM modulation
12 FAST 16-QAM 16-QAM modulation
13 FAST 9980 kbps 9980 kbps max data rate
14 FAST Hdr Comp IP Header Compression
15 FAST Data Comp IP Datagram Compression
16 FAST IP QoS IP Quality of Service
17 FAST 3xDES IP 3xDES Encryption
18 FAST Vipersat Management by VMS
19 FAST VFS Vipersat File Streamer
