Mocomtech CDM-570 User Manual
Page 164
CDM-570/570L Satellite Modem with Optional IP Module
Revision 4
Front Panel Operation
MN/CDM570L.IOM
6–40
(CONFIG, ODU, LNB) 10MHz
If 10MHz is selected, the following sub-menu is displayed:
Select On or Off , using the ◄ ► arrow keys, then press ENTER.
(CONFIG, ODU, LNB) ALARM
If Alarm is selected, the following sub-menu is displayed:
Select Upper or Lower , using the
◄ ►
arrow keys, then press ENTER.
If Upper is selected, the following sub-menu is displayed:
Edit the LNB Current Alarm Upper limit. This is accomplished by
selecting the digit to be edited, using the
◄ ►
arrow keys. The value of
the digit is then changed using the
▲ ▼
arrow keys. The user should
then press ENTER. The range of current is 50 to 600 mA.
If Lower is selected, the following sub-menu is displayed:
Edit the LNB Current Alarm Lower limit. This is accomplished by
selecting the digit to be edited, using the
◄ ►
arrow keys. The value of
the digit is then changed using the
▲ ▼
arrow keys. The user should
then press ENTER. The range of current is 10 to 400 mA.
LNB 10MHz Reference:
On Off (
◄ ►,ENTER)
Set LNB Current Alarm:
Upper Lower (
◄ ►,ENTER)
LNB Current Alarm Upper
Limit: 200mA (
◄ ►,▲ ▼,ENT)
LNB Current Alarm Lower
Limit: 050mA (
◄ ►,▲ ▼,ENT)
