CDM-570/570L Satellite Modem with Optional IP Module
Revision 4
Serial Remote Control
MN/CDM570L.IOM
13–21
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
Response to
Command
Query
(Instruction
Code and
Qualifier)
Response to Query
Initialize
Events Pointer
IEP= None Command
only.
Resets internal pointer to allow RNE? queries to start at the
beginning of the stored events log.
IEP=
IEP#
N/A N/A
Statistics
Sample
Interval
SSI=
1 byte,
numerical
Command or Query.
Used to set the sample interval for the Statistics Logging Function
SSI=x, where x= 0 to 9 in 10 minute steps.
Note: Setting this parameter to 0 disables the statistics logging
function.
Example: SSI=3 means 30 minutes
SSI=
SSI?
SSI*
SSI#
SSI? SSI=x
(see description for
details of argument)
Number of
Unread stored
Statistics
N/A
3 bytes
Query only.
Unit returns the number of stored Statistics, which remain Unread,
in the form xxx.
Note: This means unread over the remote control.
Example: NUS=247
N/A NUS? NUS=xxx
(see description of
arguments)
Retrieve next 5
unread Stored
Statistics
N/A
130 bytes
Query only.
Unit returns the oldest 5 Stored Statistics, which have not yet been
read over the remote control. Reply format:
{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body, where Sub-body=
AA.ABB.BC.CD.Dddmmyyhhmmss,
AA.A=Minimum Eb/No during sample period.
BB.B=Average Eb/No during sample period.
C.C=Max. Tx Power Level Increase during sample period.
D.D=Average Tx Power Level Increase during sample period.
ddmmyyhhmmss = date/time stamp.
If there are no new events, the unit replies with RNS*. If there are
less than 5 statistics to be retrieved, the remaining positions are
padded with zeros.
N/A RNS? RNS={CR}AA.ABB.B
C.CD.Dddmmyyhhmms
s{CR}AA.ABB.BC.CD.
Dddmmyyhhmmss{
CR}AA.ABB.BC.CD.D
ddmmyyhhmmss{CR}A
A.ABB.BC.CD.Dddmm
yyhhmmss{CR}AA.AB
B.BC.CD.Dddmmyyhh
mmss
(see description for
details of arguments)
Clear All
Stored
Statistics
CAS=
None
Command only.
Forces the software to clear the software statistics log.
Example: CAS=
Note: This command takes no arguments.
CAS=
CAS?
CAS*
CAS#
N/A N/A
