CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.4.5 (ODU,ENABLE, CONFIG,TRANSMITTER) ATTEN (Attenuation)
ODU Tx Attenuation:
15 dB (
◄ ►,▲ ▼, ENT)
The user is prompted to edit the transmit attenuation. This is accomplished by selecting
the digit to be edited, using the ◄ ► keys. The value of the digit is then changed using
the ▲ ▼ keys. The user then presses ENT.
F.3.4.6 (ODU,ENABLE,CONFIG,TRANSMITTER) OUTPUT
KST Tx Output:
Off On Warm (
◄ ►,E NT)
The user is prompted to select either ON, OFF, or WARM using the ◄ ► keys, then
press ENT.
• WARM is OFF, if COLD.
• WARM is ON, if warm and NO FAULTS
• FAULTS present, stays WARM and OFF indefinitely
F.3.4.7 (ODU,ENABLE,CONFIG,TRANSMITTER) HPA
HPA: State Fault-Logic
(
◄ ►,E NT)
The user may select a parameter using the
◄ ► keys, then press ENT.
F.3.4.8 (ODU, ENABLE,CONFIG,TRANSMITTER) STATE
KST HPA State:
On Off (
◄ ►,E NT)
Note: If the HPA power is Off, it cannot report errors, answer messages, provide serial
numbers, etc.
F.3.4.9 (ODU,ENABLE,CONFIG, TRANSMITTER) FAULT-LOGIC
HPA Fault Logic: Summary
No-Summary (
◄ ►,E NT)
The user may select from the options shown, using the ◄ ► keys, then press ENT.
This controls whether or not HPA fault will activate the SUMMARY FAULT RELAY.
