CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Appendix F MN/CDM570L.IOM
F.3.4 KST2000A/B Menus
F.3.4.1 (ODU,ENABLE) Selections
KST SELECT: Config Info
Status (◄ ►,ENT)
The user is prompted to select 1 of 3 sub-menu branches using the ◄ ► keys, then press
ENT.
F.3.4.2 (ODU,ENABLE) CONFIG (Configuration)
KST CONFIG: Transmitter
Receiver Misc (◄ ►,ENT)
The user uses this menu item to select either the ‘Transmitter configuration branch”,
“Receiver configuration branch” or “Misc configuration branch”. Use the ◄ ► keys,
then press ENT.
F.3.4.3 (ODU,ENABLE,CONFIG) TRANSMITTER
KST TX: Frequency Atten
Output HPA (◄ ►,ENT)
This menu item is used to select which ODU Transmitter parameter is to be modified.
Use the ◄ ► keys, then press ENT.
F.3.4.4 (ODU,ENABLE,CONFIG,TRANSMITTER) FREQUENCY
ODU Tx Frequency:
14500.0 MHz (
◄ ►,▲ ▼, ENT)
The user is prompted to edit the transmit frequency. This is accomplished by selecting
the digit to be edited, using the ◄ ► keys. The value of the digit is then changed using
the ▲ ▼ keys. The user may then press ENT.
The frequency limits of the KST-2000A are known and the frequency values are
constrained accordingly.
F–18
