CDM-570/570L Satellite Modem with Optional IP Module
Revision 4
Appendix F
MN/CDM570L.IOM
F.3.3.8 (ODU,ENABLE,1:1,CSAT#1)
Selections
(ODU,ENABLE,1:1,CSAT#2)
Selections
(ODU,ENABLE,STAND-ALONE)
Selections
ODU SELECT: Config Info
Monitor Alarms (
◄ ►
,ENT)
The user is prompted from 1 of 4 sub-menu branches using the
◄ ►
arrow keys, then
press ENT.
F.3.3.9 (ODU,ENABLE,1:1,CSAT#1)
CONFIG (Configuration)
(ODU,ENABLE,1:1,CSAT#2)
CONFIG
(Configuration)
(ODU,ENABLE,STAND-ALONE)
CONFIG (Configuration)
ODU CONFIG: Transmitter
Receiver Misc (
◄ ►
,ENT)
The user uses this menu item to select either the ‘Transmitter configuration branch”,
“Receiver configuration branch” or “Miscellaneous configuration branch”. Use the
◄ ►
arrow keys, then press ENT.
F.3.3.10 (ODU,ENABLE,1:1,CSAT#1,CONFIG) TRANSMITTER
(ODU,ENABLE,1:1,CSAT#2,CONFIG)
TRANSMITTER
(ODU,ENABLE,STAND-ALONE,CONFIG)
TRANSMITTER
ODU TX: Frequency Atten
Amplifier Mute Slope
◄ ►
This menu item is used to select which ODU Transmitter parameter is to be modified.
Use the
◄ ►
arrow keys, then press ENT.
F–5
