CDM-570/570L Satellite Modem with Optional IP Module Revision 4
IP Module - CLI and Telnet Operation MN/CDM570L.IOM
Menu Options/Fields Entry Description
Data Interface I 1 -- EAI-422/EAI-530 DCE
2 -- V.35 DCE
3 -- EAI-232(sync)
4 -- G.703 T1 AMI
5 -- G.703 T1 B8ZS
6 -- G.703 E1 Unbal AMI
7 -- G.703 E1 Unbal HDB3
8 -- G.703 E1 Bal AMI
9 -- G.703 E1 Bal HDB3
10 -- IP Interface
Note: The data interface must be set to IP
Interface for IP traffic to pass over the satellite.
Save Parameters S This option allows a user to save the current
configuration to permanent storage. This
configuration will be restored on each
successive power cycle.
Exit X This option allows a user to exit the current
menu and return to its parent menu.
17.2.8.5 Reference Configuration
The Reference Configuration page is activated from the Configuration page.
The Reference Interface Configuration page contains the following options/fields:
