Mocomtech CDM-570 - Manual (Page 305)

CDM-570/570L Satellite Modem with Optional IP Module Revision 4
IP Module - CLI and Telnet Operation MN/CDM570L.IOM
17.2.1 Administration Page
The Administration page is activated from the Main Menu page.
IMPORTANT
Access to the Administration page is restricted to the Admin user when connecting
via the Telnet, SNMP, or HTTP interface. The Administration page is available when
connected via the Terminal Emulator (serial) connection because there is no log in.
The Administration page contains the following options/fields.
Menu Options/Fields Entry Description
Name/Password
Configuration P Activates Name/Password Configuration page. Allows
the user to define the user name and passwords that
are required in order to access the management
interfaces.
Access Lists A Activates Access Lists page. Allows the user to restrict
access to the management interfaces based upon the
requester’s IP address.
Feature Configuration F Activates Feature Configuration page.
17–5
