CDM-570/570L Satellite Modem with Optional IP Module Revision 4
IP Module Ethernet Interface Overview MN/CDM570L.IOM
• Configuration backup and restore via FTP
• Event Logging to capture all IP Module activity
• Detailed Statistics of IP traffic
• IGMP support for multicast
• CDM-550 Emulation Mode
• Static IP routing for unicast and multicast
• easyConnect™ Mode
15.3.1 10/100BaseT Ethernet Interface
In Router Mode operation, the 10/100BaseT Ethernet Interface is used for routing IP
traffic to be transmitted over the satellite or routed to another device on the local LAN. In
easyConnect
™ Mode, the Ethernet Interface is used to forward IP and non-IP traffic over
the satellite. Local or remote management of all CDM-570/570L and IP Module
functions is also available via Telnet, HTTP, or SNMP.
15.3.2 Powerful Network Management
The CDM-570/570L IP-Centric Modem may be configured, operated and monitored
using any of the following methods:
User Interface Connection Modem
Functions IP Module
Functions Reference
Front Panel
Local - Keypad ALL IP Address/Subnet
Mask only Chapter 6
Serial Remote
Control Local - Serial RS-232/RS-485
via Remote Control Port ALL IP Address/Subnet
Mask only
Chapter 14
Serial Command
Line Interface (CLI) Local - Serial RS-232 via
Console Port ALL ALL Chapter 17
Telnet
Local or remote - Ethernet via
10/100 BaseT Traffic interface ALL ALL Chapter 17
Web Server
Local or remote - Ethernet via
10/100 BaseT Traffic interface ALL ALL Chapter 18
SNMP
Local or remote - Ethernet via
10/100 BaseT Traffic interface ALL ALL Chapter 19
15.3.3 Remote software/firmware upgrade via FTP
The IP Module uses ‘flash memory’ technology internally, and new firmware can be
uploaded to or from an external PC by FTP. This makes software upgrading very simple,
and updates can now be sent via the Internet, E-mail, or on disk. The upgrade can be
performed without opening the unit or having to be in the same physical location.
