CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Front Panel Operation MN/CDM570L.IOM
6–27
If Spectrum is selected, the following sub-menu will be displayed:
Select Normal or Inverted, using the
◄ ► arrow keys, then press ENTER.
If Data is selected, the following sub-menu will be displayed:
Select Normal or Inverted, using the ◄ ► arrow keys, then press ENTER.
6.8.10 (CONFIG, RX) Eb/No
Edit the Eb/No alarm point. This is accomplished by selecting the digit to be edited, using
the
◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys.
The user should then press ENTER.
The range of values is from 0.1 to 16.0 dB. The user may select a value here, and if the
Eb/No falls below this value, a receive traffic fault will be generated.
6.9 (CONFIG) FRAME (Framing Mode)
Select Unframed, EDMAC or EDMAC-2, using the
◄ ► arrow keys, then press
ENTER.
The sub-branches available are:
Eb/No Alarm Point:
02.0 dB (
◄ ►,▲ ▼,ENTER)
Framing Mode: Unframed
EDMAC EDMAC-2 (
◄ ►,ENT)
Rx Spectrum: Normal
Inverted (
◄ ►,ENTER)
Rx Data Sense: Normal
Inverted (
◄ ►,ENTER)
