CDM-570/570L Satellite Modem with Optional IP Module
Revision 4
Installation
MN/CDM570L.IOM
Equipment
Rack
Mounting
Rail
#10 Shoulder Screw
BRACKET
BOLTS
Support
Bracket
Back of Modem
Bracket
#10 Split W asher
#10 Flat W asher
#10 Flat W asher
#10 Hex Nut
Figure 2-1. Installation of the Optional Mounting Bracket
2–3
