Operation and Maintenance MultiVOIP User Guide
422
Logs Screen Details: Field Definitions
Field Name Values Description
Log # column 1 or higher All calls are assigned an event
number in chronological order,
with the most recent call having
the highest event number.
Start Date,Time
column dd:mm:yyyy
hh:mm:ss The starting time of the call (event).
The date is presented as a day
expression of one or two digits, a
month expression of one or two
digits, and a four-digit year. This is
followed by a time-of-day expression
presented as a two-digit hour, a two-
digit minute, and a two-digit seconds
value. (statistics, logs) field
Duration column hh:mm:ss
This describes how long the call
(event) lasted in hours, minutes, and
seconds.
Status column success or
failure Displays the status of the call, i.e.,
whether the call was completed
successfully or not.
Mode column voice or FAX Indicates whether the (event) being
described was a voice call or a FAX
call.
From column gateway name Displays the name of the voice
gateway that originates the call.
To column gateway name Displays the name of the voice
gateway that completes the call.
Special Buttons
Previous -- Displays log entry before
currently selected one.
Next -- Displays log entry after currently
selected one.
First -- Displays first log entry
Last -- Displays last log entry.
Delete File -- Deletes selected log file.
Call Details
Packets sent integer value The number of data packets sent
over the IP network in the course
of this call.
Bytes sent integer value The number of bytes of data sent
over the IP network in the course
of this call.
