T1 Phonebook Configuration
MultiVOIP User Guide
328
Add/Edit Outbound Phone Book: Field Def’ns
(cont’d)
Field Name
Values
Description
SPP Fields
Use Registrar
Values:
Y/N
Description:
Select this checkbox to use registrar
when voip system is operating in the
“Registrar/Client” SPP mode. In this mode, one
voip (the registrar, as set in Phonebook
Configuration screen) has a static IP address and
all other voips (clients) point to the registar’s IP
address as functionally their own. However, if
your voip system overall is operating in
“Registrar/Client” mode but you want to make an
exception and use Direct mode for the destination
pattern of this particular Add/Edit Phonebook
entry, leave this checkbox unselected.
Leave this checkbox unselected if your overall voip
system is operating in the “Direct" SPP mode. In
this mode, all voips in system are peers and each
has its own static IP address.
Port Number
Values:
numeric
Description:
When operating in
“Registrar/Client” mode, this is the port by which
the gateway receives all SPP data and control
messages from the registrar gateway. (This ability
to receive all data and messages via one port
allows the voip to operate behind a firewall with
only one port open.)
When operating in “Direct” mode, this is the Port
by which peer voips receive data and messages.
Alternate
Phone Number
numeric Phone
number
associated
with alternate IP routing.
Remote Device
is [legacy voip]
Y/N
When checked, this
MultiVOIP can operate with
‘first-generation’ MultiVOIP
units in the same IP network.
These include MVP-
110/120/200/400/800.
Advanced
button
Values:
N/A
Description:
Gives access to secondary screen
where an Alternate IP Route can be specified
for backup or redundancy of signal paths.
See discussion on next page. For SIP & H.323
operation only.
