DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
17 OUTLET CTR 15A Accessory socket (Center)
18 OUTLET RR 15A Accessory socket (Rear)
19 AC PWR 15A Moon roof
í
, DC/AC inverter
20 S.WARM 15A Seat warmer
í
21 A/C MAG 10A Air conditioner
22 BOSE 25A Audio system (Bose
®
Sound System-equipped model)
í
23 FAN2
30A
í
Cooling fan
40A
í
24 ABS 50A ABS
25 IG COIL 25A Ignition system
26 H/L LOW L 15A Headlight-left (Low beam)
27 H/L LOW R 15A Headlight-right (Low beam)
28 H/L HIGH 20A Headlight-high (High beam)
29 HAZARD 15A Hazard warning flashers
30 ENG +B 10A PCM
31 HORN 15A Horn
32 STOP 7.5A Brake lights
33 EGI INJ 10A Engine control system
34 ENG BAR 20A Air flow sensor, EGR control valve
35 ENG BAR 2 7.5A PCM
8-48
Maintenance and Care
í
Some models.
