NOTE
l Setting the temperature to the maximum
high or low will not provide the desired
temperature at a faster rate.
l When selecting heat, the system will restrict
airflow until it has warmed to prevent cold
air from blowing out of the vents.
l While in individual operation mode, the
temperature setting is controlled at the
driver's temperature.
l When operating the air conditioning from
the front seats (REAR CONTROL switch is
off), operation from the rear seats is not
possible.
l Airflow amount and the mode for the rear
cannot be changed by operating the mode
selector switch of the front control panel.
Airflow amount and the mode are
automatically changed according to the
temperature control dial.
Airflow amount automatically changes
according to the fan control dial of the front
control panel.
Operation from rear seats
1. Turn the front air conditioning on.
2. Turn the REAR CONTROL switch on
in the front control panel. (indicator
light illuminated.)
NOTE
“CONTROL ON” illuminates in the REAR
CONTROL panel.
3. Set the temperature control dial to the
desired position.
Cold Hot
NOTE
The airflow mode may change depending on
the set temperature.
4. Set the fan control dial to the desired
position.
Slow Fast
6-16
Interior Comfort
Climate Control System
