The quality designation SM, or ILSAC
must be on the label.
5W-20
120 100 80 60 40 20 0 –20
50 40 30 20 10 0 –10 –20 –30
qInspecting Engine Oil Level
1. Be sure the vehicle is on a level
surface.
2. Warm up the engine to normal
operating temperature.
3. Turn it off and wait at least 5 minutes
for the oil to return to the oil pan.
4. Pull out the dipstick, wipe it clean, and
reinsert it fully.
Max
Min
5. Pull it out again and examine the level.
It's OK between MIN and MAX. But if
it's below MIN, add oil to raise the
level within the hatching zone.
CAUTION
Don't add engine oil over MAX. This
may cause engine damage.
6. Make sure the O-ring on the dipstick is
positioned properly before reinserting
the dipstick.
8-20
Maintenance and Care
Owner Maintenance
