OPERATING GUIDE
.
80
Appendix B: Key codes
Figure 57 illustrates the keys on a standard 104 key PC keyboard with a US
English language mapping. These keys are used to define keystrokes or hotkeys
for several Smart 16 IP functions. The keys may not represent keys used on
international keyboards. Most modifier keys and other alphanumeric keys are in
identical positions, whichever language mapping you are using.
Figure 57 US English keyboard layout
The table below lists keys that that have 2 ways of being written (Alternative) and
also keys that are written in a different way to that which appears on the actual
keyboard key (Key code).
Key Key code Alternative
~ ~ TILDE
- - MINUS
= = EQUALS
< < LESS
/ / SLASH
Bksp BACK_SPACE
Tab TAB
CR ENTER
Caps CAPS_LOCK
\ \ BACK_SLASH
Lshft LSHIFT SHIFT
Lctrl LCTRL CTRL
Win WINDOWS
Alt LALT ALT
AltGR ATGR
Esc ESCAPE ESC
Psc PRINTSCREEN
