NOTE If you plan to dial into your PLC via GSM, you will possibly need a SIM card and account with
data service enabled. However, in some cases the modem may be capable of accepting
data calls on a voice number after using the AT+CICB=0 command. For detailed information,
contact your mobile service provider.
E
ATTENTION:
The SIM card should only be removed when the modem is in power-off state.
The SIM card may become unusable if this warning is not observed.
Normal Modem GSM (MIM-G01) Mounting and Installation
3 - 6 MITSUBISHI ELECTRIC
SIM-Card
Antenna
027954
541034
-
+ 10...40
V DC
SIM-Card
Pus h Status
GSM Po we r
Fig. 3-5:
Insert the SIM card with the contact side
facing upwards and ensure that the card
is seated correctly in the recess.
Then push the SIM card holder back into
the modem until it snaps into position.
