Mercedes-Benz 2004 G 500 - Manual (Page 328)

328
Technical data
Engine
̄ Engine
G 500 (463.249 1 )
1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Light Truck Center for the corresponding data of all special bodies and special
equipment.
G 55 AMG (463.246) 1
Engine 113 113
Mode of operation 4-stroke engine, gasoline injection 4-stroke engine, gasoline injection
No. of cylinders 8 8
Bore 3.82 in (97.00 mm) 3.82 in (97.00 mm)
Stroke 3.31 in (84.00 mm) 3.60 in (92.00 mm)
Total piston displacement 303.0 cu in (4966 cm 3 ) 331.8 cu in (5439 cm 3 )
Compression ratio 10:1 10.5:1
Output acc. to SAE J 1349 292 hp/5500 rpm
(218 kW/5500 rpm) 349 hp/5500 rpm
(260 kW/5500 rpm)
Maximum torque acc. to SAE J 1349 336 lb-ft/2800 - 4000 rpm
(456 Nm/2800 - 4000 rpm) 391 lb-ft/3250 rpm
(530 Nm/3250 rpm)
Maximum engine speed 6000 rpm 6000 rpm
Firing order 1-5-4-2-6-3-7-8 1-5-4-2-6-3-7-8
Poly-V-belt 2380 mm 2380 mm
