159
Controls in detail
Climate control
Increasing
̈ Turn the temperature control a few de-
grees to the right.
The climate control system will corre-
spondingly adjust the interior air tem-
perature.
Decreasing
̈ Turn the temperature control a few de-
grees to the left.
The climate control system will corre-
spondingly adjust the interior air tem-
perature.
Adjusting air distribution and volume
Use air distribution control 4
( ୴ page 157) to adjust the air distribution.
The following symbols are found on the
controls:
Adjusting manually
̈ Press the U button.
The indicator lamp on the button goes
out.
̈ Select any of the six air volume speeds
and the air distribution.
Symbol Function
a
Directs air through the center,
side and rear passenger com-
partment air vents
Z
Directs air to the windows
X
Directs air into the entire vehi-
cle interior
Y
Directs air to the footwells
