IN-5
Index
A
asterisk (*) 4
B
backplane connector 3-1
C
cables, user-supplied
on MVME712-12/12A 2-12
SCSI interface to MVME712B 2-16
Telco modular 2-14
caution 2-11
configuration
of modem port 2-7
serial port 2-7
connector
EIA-232D 3-2
EIA-232D serial port 3-1
Ethernet 3-1, 3-13, 3-15
modem 3-9, 3-14
modem interconnect 3-1
modem power 3-1
modem TIP/RING 3-1
P2 3-1, 3-2
SCSI 3-11
serial port 3-1
Telco modular jack 3-1
telephone 3-20, 3-21, 3-22
connector locations
on LCP2 adapter 2-10
on MVME712B 2-9
cooling requirements 1-3
D
data rates A-1
depth, MVME712x 1-2
documentation, related 3
DSR line pull up select headers 2-6
E
EIA-232D
connectors 3-2
interconnect signals 3-2
serial ports 1-1
Electrostatic Discharge (ESD) protection
1-2
ETHERNET 3-13
Ethernet connector 3-1, 3-13, 3-15
Ethernet interface 1-2
F
FCC compliance 1-3
fuses
on LCP2 and MVME1xx 2-13, 2-17
G
general description 1-4
H
height, MVME712x 1-2
I
I/O ports 1-2
installation
of modules 2-1
of MVME712B 2-16
