General Information
1-2 MVME712-12/-13/A/AM/B Transition Modules and LCP2 Adapter Board UserÕs Manual
1
❏ External Ethernet interface (through the LCP2 adapter) (MVME712B)
❏ Built-in modem (refer to Appendix A) with front panel Telco modular jack
(MVME712-13 and MVME712AM)
❏ Electrostatic Discharge (ESD) protection on front panel
❏ Radio Frequency Interference (RFI) protection on front panel
Features of the LCP2 Adapter Board
The features of the LCP2 Adapter Board include:
❏ A 50-pin connector permits SCSI cable connection to other SCSI devices
and/or to the MVME712B through a flat ribbon cable
❏ SCSI terminating resistors mounted in sockets for end of cable or middle of
cable configuration
❏ Terminator power is developed on the LCP2 adapter from the +5 Vdc on
connector P2 and is fused (1 amp) on the LCP2 adapter
❏ A 64-pin connector interfaces the EIA-232D ports and printer port signals
to the MVME712
x
Specifications
The MVME712 family module specifications are given in Table 1-1.
Table 1-1. MVME712 Family Specifications
Characteristics SpeciÞcations
Power requirements + 5 Vdc, 281 mA maximum (255 mA typical)
+12 Vdc
- 12 Vdc
I/O ports Serial Four multiprotocol (connected through the
LCP2 adapter)
Parallel Parallel printer port (connected through the
LCP2 adapter)
Operating temperature 0 degrees to 55 degrees C at point of entry of
forced air (approximately 5 CFM)
Storage temperature - 40 degrees to 85 degrees C
Relative humidity 5% to 90% (non-condensing)
Physical characteristics
(excluding front panel
and MVME712B) Height
Depth
Thickness 9.187 inches (233.35 mm)
3.200 inches (80.00 mm)
0.063 inches (1.60 mm)
