6. Push and release the FOLD
switch (FIG. 54 -3) two
times to access the FLOOR
POS setting (FIG.
54 -4).
HAND PENDANT:
CHANGING SETUP MODE
FIG. 54-3
5. Enter SETUP by holding both
the UP and FOLD switches on
the hand pendant (FIG.
54 -1)
and turning the power switch
ON at the same time (FIG. 53-
3). Controller will read SETUP
(FIG.
54 -2).
SETUP
CONTROLLER:
ENTERING SETUP
FIG. 54-2
HAND PENDANT:
ENTERING SETUP
FIG. 54-1
CONTROLLER:
SETTING FLOOR POSITION
(EXAMPLE READING SHOWN)
FIG. 54-4
FLOOR POS: 345
UP
FOLD
FOLD
FLOOR POSITION ADJUSTMENT - Continued
