PATENTS PENDING 40
11921 Slauson
A
ve. Santa Fe Springs, CA. 90670 (800) 227-41
16 F
AX (888) 771-7713
3. Pull out fi ller cap (FIG. 40-1). Fill the
reservoir with hydraulic fl uid (TABLE
40-1) to level shown in FIG. 40-1.
Reinstall fi ller cap (FIG. 40-1).
4. Bolt on the pump cover as shown
in FIG. 39-2. Tighten the 5/16”-18
cover screws until snug.
TABLE 40-1
RECOMMENDED HYDRAULIC FLUID
BRAND PART NUMBER
ROSEMEAD THS FLUID 17111
EXXON UNIVIS HVI 26
HYDRAULIC FLUID LEVEL
(LH PUMP SHOWN)
FIG. 40-1
RESERVOIR
FILLER
CAP
2”
NOTE: If the expected seasonal
temperatures are below
20°F, use MIL-H-5606G
hydraulic fl uid.
CHECKING HYDRAULIC FLUID LEVEL - Continued
