PATENTS PENDING 37
11921 Slauson
A
ve. Santa Fe Springs, CA. 90670 (800) 227-41
16 F
AX (888) 771-7713
13. Connect short power cable to vehicle
battery as follows. Remove nut from
positive (+) battery terminal connec-
tor (FIG. 37-1). Connect the power
cable.
Reinstall nut.
CONNECTING POWER TO LIFT (TYPICAL)
FIG. 37-1
POSITIVE (+) BATTERY
TERMINAL
SHORT POWER
CABLE
BOLT
NUT
14. Turn ON power ON/OFF switch on
pump cover to power the Lift (FIG.
37-2). The POWER light on hand
pendant should be illuminated (FIG.
37-3). Briefl y press the FOLD button
on hand pendant (FIG. 37-3) to pres-
surize hydraulic system. Then, remove
remaining shipping straps.
STOWED LIFT - LH SIDE SHOWN
FIG. 37-2
POWER ON/OFF
SWITCH
HAND PENDANT
FIG. 37-3
UP FOLD
UNFOLD FOLD
POWER
LIGHT
