Lift dimensions – Maxon Telecom WL7-VERS. C User Manual
Page 11

PATENTS PENDING
11
11921 Slauson
A
ve. Santa Fe Springs, CA. 90670 (800) 227-41
16 F
AX (888) 771-7713
E
55.13”
LIFT DIMENSIONS
FRONT VIEW OF STOWED LIFT
(LH PUMP MODEL SHOWN)
(SEE TABLE 11-1)
FIG. 11-2
F
SIDE VIEW OF STOWED LIFT
(LH PUMP MODEL SHOWN)
FIG. 11-1
D
C
25”
39”
18-3/4”
TABLE 11-1
13.3”
18.9”
2.9”
1.4”
0.5”
C
D
E
F
MODEL
DESCRIPTIONS
LIFT WIDTH AT
WARNING BEACONS
LIFT WIDTH AT
HANDRAILS
LIFT WIDTH AT
BASE PLATE
OVERALL LIFT
WIDTH (INCLUDING
PUMP COVER)
30” WIDE PLATFORM
RH PUMP
40.25”
38”
39.5”
45.5”
30” WIDE PLATFORM
LH PUMP
33” WIDE PLATFORM
RH PUMP
43.25”
41”
42.5”
48.5”
33” WIDE PLATFORM
LH PUMP
34” WIDE PLATFORM
RH PUMP
44.25”
42”
43.5”
49.5”
34” WIDE PLATFORM
LH PUMP
4.75”
