DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 97
KUBOTA Z482-EB/E2B/E3B ENGINE — GEAR CASE ASSY.
GEAR CASE ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
010
1687504024
COMP. CASE, GEAR, Z482EB, Z482E2B .........1................INCLUDES ITEMS W/#
010
1E05104024
COMP. CASE, GEAR, Z482E3B ........................1................INCLUDES ITEMS W/%
020#% 1685196010
PLUG .................................................................2................Z482EB
020#% 1552196030
PLUG .................................................................2................Z482-E2B AND Z482-E3B
030#% 1584156280
PIN, START SPRING
1
040
0481406130
O-RING ..............................................................3................Z482-EB AND Z482-E2B
050
1586204132
GASKET, GEAR CASE .....................................1................Z482-EB AND Z482-E2B
050
1586204130
GASKET, GEAR CASE .....................................1................Z482-E3B
060 0102350618
BOLT
1
070 0102360650
BOLT
8
080 1584191010
BOLT
5
090 0102350670
BOLT
..................................................................1................Z482EB
090
0102360670
BOLT ..................................................................1................Z482E2B AND Z482-E3B
100 0102350675
BOLT
1
130 1587704140
SEAL,
OIL
1
150 1685136950
SPRING
1
160 1584136930
SEAT,
VALVE
1
170 0771503211
BALL
1
180
1584633110
FLANGE, OIL FILLER
1
190
1381133140
PLUG, OIL FILLER
1
200 0481106230
O-RING
1
210
1946188132
GASKET, H/M GEAR CASE
1
220 1522188210
STUD
3
230 0205650060
NUT
3
240 0451260060
WASHER,
LOCK
3
