PAGE 12 — DA7000 SERIES GENERATORS• OPERATION AND PARTS MANUAL — REV. #5 (01/20/11)
SPECIFICATIONS (GENERATOR)
Table 1. Specifi cations (Generator)
AC Generator
60 Hz AC Power Source
Model
DA7000SS/DA7000SSA
DA7000SSW/DA7000SSWGH
Type 2-Pole Brushless Revolving Field Type
Excitation Solid State, Statically Excited System
Speed 3,600 RPM
Cooling System Self-Ventilation
Max Power Output 7 kW
Continuous Power Output 6 kW
Rated Voltage 120/240V
Current Max/Continuous (120V) 58.3/50 amps
Current Max/Continuous (240V) 29.2/25 amps
Phase Single Phase (4 wire)
Frequency 60 Hz
Power Factor 1
Battery 12V -35Ah
Dimensions
(L x W x H) 25.6 x 44.9 X 31.3 in.
(650 X 1,140 X 795 mm)
Dry Net Weight 526 lbs. (239 kg)
NOTICE
In keeping with Multiquip's policy of constantly
improving its products, the specifi cations quoted herein
are subject to change without prior notice.
