DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 67
CONTROL PANEL ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1 A5225000303
CONTROL
PANEL
1
1 A5511302402
CONTROL
PANEL
.............................................1................DA7000SSA
2 0021805020 MACHINE
SCREW
4
3 0601800258 AC
VOLTMETER,
120/240
1
4 0207003000 HEX
NUT
2
5
0601807456
CIRCUIT BREAKER, KM52 265V 25A
1
6
4341817004
BRACKET CIRCUIT BREAKER
1
7 0021004016 MACHINE
SCREW
2
8
0601830771
IDLE CONTROL SWITCH
1
9
1628663602
STARTER SWITCH ...........................................1................REPLACES 0602100077
9A 3741055150 IGNITION,
KEY
10 0601810523 INDICATOR
ASSY.
1
10A 0601810830
BULB
4
11
0601800682
HOUR METER 820114
1
12 0027403512 MACHINE
SCREW
2
12A 0030003500
HEX
NUT
2
13
0601811034
RECEPTACLE CS6369 125 250V 50A ..............1................REPLACES 0601812566
14
0601812529
RECEPTACLE, L14- 30R 125V 30A
1
15
0601811031
RECEPTACLE, L5-30R 125V 30A .....................1................REPLACES 0601811035
16
0601812597
RECEPTACLE, 5-20R 120V 20A ......................1................REPLACES 0601812598
17 0021004010 MACHINE
SCREW
8
17A
0030004000
HEX NUT ...........................................................8................REPLACES 0207004000
18
0601806420
CIRCUIT PROTECTOR, AC 250V 20A
1
19 0027103005 MACHINE
SCREW
2
20 0601815109 GROUND
TERMINAL
1
