DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 111
KUBOTA Z482-EB/E2B/E3B ENG. — PISTON AND CRANKSHAFT ASSY.
PISTON AND CRANKSHAFT ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
010
1685121112
PISTON STD ...................................................2................Z482-EB AND Z482-E2B
010
1685121114
PISTON STD ...................................................2................Z482-E3B
010
1685121900
PISTON +0.25MM ..............................................2................Z482-EB AND Z482-E2B
010 1685121903
PISTON
+0.25MM
..............................................2................Z482-E3B
020
1685321050
ASSY. PISTON RING STD
2
020
1685321090
ASSY. PISTON RING +0.25MM
2
030 1685121310
PIN,
PISTON
2
040
1526121330
AIR CLIP, PISTON PIN
4
050
1685122010
CONNECTING ROD ASSY., Z482-EB...............2................INCLUDES ITEMS W/%
050
1685122015
CONN. ROD ASSY. Z482-E2B/E3B ...................2................INCLUDES ITEMS W/+
060% 1685121980
BUSH, PISTON PIN ...........................................2................Z482-EB
060+
1685121982
BUSH, PISTON PIN ...........................................2................Z482-E2B AND Z482-E3B
070%+ 1685122140
BOLT, CONNECTING ROD
4
080%+ 1685122320
METAL, CRANKPIN M STD SET
2
080
1586122970
METAL, CRANKPIN -0.20MM SET
2
080
1586122980
METAL, CRANKPIN -0.40MM SET
2
090
1685323030
CRANKSHAFT ASSY. ........................................1................INCLUDES ITEMS W/#
100# 0771503207
BALL
2
110# 1921523280
SLEEVE,
CRANKSHAFT
1
120 1584124110
GEAR,
CRANK
1
130 0571200515
KEY,
FEATHER
1
140
1586123470
METAL, CRANKSHAFT STD
1
140
1586123910
METAL, CRANKSHAFT -0.20MM
1
140
1586123920
METAL, CRANKSHAFT -0.40MM
1
150
1686123480
METAL, CRANKSHAFT M STD SET
1
150
1569423930
METAL, CRANKSHAFT -0.20MMSET
1
150
1569423940
METAL, CRANKSHAFT -0.40MMSET
1
160
1686123490
METAL, CRANKSHAFT STD SET
1
160
1586123860
METAL, CRANKSHAFT -0.20MM SET
1
160
1586123870
METAL, CRANKSHAFT -0.40MM SET
1
170
1526123530
METAL, SIDE STD
2
170
1526123950
METAL, SIDE +0.20MM
2
170
1526123960
METAL, SIDE +0.40MM
2
180
1526123540
METAL, SIDE STD
2
180
1526123970
METAL, SIDE +0.20MM
2
180
1526123980
METAL, SIDE +0.40MM
2
190 1584123250
COLLAR,
CRANKSHAFT
1
200 1588123310
SLINGER,
OIL
1
210 0481416220
O-RING
1
